Vibration control

Field of application

• Decoupling of traverses and pipe bridges made of MPC-Support channels

Advantages

• Noise decoupling integrated into the hanger
• Very good vibration improvement of up to 17 dB(A) due to the highly elastic DÄMMGULAST® Spring element
• Attachment for threaded rods M8, M10 or alternatively for stripmounting, depending on type
• The design for strip-mounting is also suitable for suspension attachment by means of hanger sockets
• Subsequent height adjustment of the threaded rods is possible

Features

Connection for	Overall height L [mm]	Max. permitted load [N]	Average vibration reduction [dB(A)]	Part no.	Sales unit	Pack unit
Threaded rods M8	40	230	16	117736	100	pieces
Threaded rods M10	110	1,000	17	117733
Strp-mounting, screws up to M8	55	230	16	117728
